| 1 |
USB-C Power Delivery, low-power profile |
Up to 20 W |
Phones, small tablets, earbuds |
Usually produces less heat than higher-power charging when the device accepts the power level. |
Use for routine charging and stop near 80–90% when full capacity is not needed. |
Use a standards-compliant charger and cable; keep vents clear. |
| 2 |
USB-C Power Delivery, standard fast-charge profile |
20–30 W |
Most modern smartphones and compact tablets |
A practical balance between charging speed and heat for compatible devices. |
Prefer this range for everyday use instead of the highest supported wattage. |
Avoid charging under pillows, in direct sunlight, or inside hot vehicles. |
| 3 |
USB-C Power Delivery, medium-power profile |
30–45 W |
Large smartphones, tablets, handheld computers |
Suitable when the device is designed for it; charging power is negotiated rather than forced. |
Use when time matters, then reduce heat and charging time near the upper battery range. |
Confirm that the device supports the required USB-C charging standard. |
| 4 |
USB-C Power Delivery, laptop profile |
45–65 W |
Ultrabooks, larger tablets, portable monitors |
Efficient for devices that regulate input power and thermal load internally. |
Enable the device’s battery-protection or charge-limit mode where available. |
Use a cable rated for the required current and power level. |
| 5 |
USB-C Power Delivery, high-power laptop profile |
90–100 W |
Performance laptops and high-capacity tablets |
Can be safe when supported, but higher power may create more heat during heavy use. |
Charge on a hard, ventilated surface and avoid intensive workloads while charging. |
Use an electronically marked cable when required by the power specification. |
| 6 |
USB-C extended-power profile |
140–240 W |
Compatible high-performance laptops and monitors |
Appropriate only for equipment specifically designed for extended-power charging. |
Use mainly when necessary; use a lower-power compatible charger for light-duty routine charging. |
Requires compatible ports, charger, cable, and thermal management. |
| 7 |
Programmable-voltage fast charging |
Device-dependent, commonly 20–65 W |
Compatible phones and tablets |
Allows the device to request a closer operating voltage, which can reduce conversion losses and heat. |
Use only with devices and chargers that support the same negotiated protocol. |
Do not assume every USB-C charger supports programmable voltage. |
| 8 |
Adaptive multi-port USB-C charger |
30–100 W shared output |
Several phones, tablets, and laptops |
Useful for avoiding unnecessary high-power chargers on lower-power devices. |
Check the actual power allocation when multiple devices are connected. |
Choose over-current, over-temperature, and short-circuit protection. |
| 9 |
Temperature-managed fast charging |
Device-dependent, commonly 20–100 W |
Devices with active thermal monitoring |
The device can reduce charging power when battery temperature rises. |
Keep software updated and do not cover the device during charging. |
Thermal control reduces risk but cannot eliminate heat-related aging. |
| 10 |
Charge-limited fast charging |
Any supported fast-charge level, limited to 70–85% |
Phones, tablets, and laptops used near a power source |
Avoiding prolonged time at 100% can reduce calendar aging and high-voltage stress. |
Set an 80% limit for routine use and charge to 100% only when extra runtime is needed. |
The limit must be supported by the device’s operating system or battery-management system. |
